Rocky Mountain Instinct PowerPlay SL A30

Frame
FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-4™ Adjustable Geometry | 145mm Travel | FORM™ Alloy Rear Triangle

Fork
RockShox Psylo Gold RC 150mm | 27.5 = 37mm Offset | 29 = 42mm Offset

Front Travel
150

Shock
SM-XL: RockShox Deluxe Select+ | 230x57.5mm | XS: RockShox Deluxe Select+ | 210x52.5mm | Sealed Bearing Eyelet | 25x8mm F Hardware | Size-Specific tune in FAQ

Rear Travel
145

Headset
FSA ZS56/66 Reach Adjust | 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race

Stem
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm

Handlebar
Rocky Mountain AM | 760mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp

Grips
ODI Elite Pro Lock On

Brakes
Shimano MT4120 4 Piston | Resin Pads

Shifters
Shimano Deore 12spd

Rear Derailleur
Shimano Deore 12spd

Cranks & Chainring
Rocky Mountain Microdrive 2PC | Race Face 34T SHI 12 Ring | 24mm Spindle | Crank Length: 165mm

Bottom Bracket
Rocky Mountain Sealed - Shimano Compatible

Cassette
Shimano Deore 10-51T 12spd

Chain
Shimano M6100

Front Hub
Shimano TC500 | 15mm Boost

Rear Hub
Shimano TC500 Boost 148mm

Spokes
DT Swiss Champion 2.0

Rims
WTB ST i30 TCS 2.0 | 28H | Tubeless Set Up | Sealant Incl

Tires
Maxxis Minion DHF 2.5 WT EXO Tubeless Ready | Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready | Tubeless Set Up | Sealant Incl

Seatpost
X Fusion Manic Composite 30.9mm |XS - SM = 125mm | MD = 150mm | LG = 170mm | XL = 200mm

Saddle
WTB Volt Race 142 | Cromoly rails

Drive System
Dyname S4 Lite Mountain Bike Drive | 250w Nominal Power | 550w Max Power | 65Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada

Battery
480 Wh Removable Integrated Li-Ion

Display
Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration

Charger
Rocky Mountain Powerplay Charger | 2A | 48V | Higo Deep Socket Connector

Weight
49 LBS|22.2 KGS
